Static torque, M0 38 Nm
Static current, I0 188 A
Rated output, Pn 5230 W
Rated torque, Mn 25 Nm
Rated current, In 11.8 A
Rated speed, nn 2000 /min
Maximum torque, Mmax 76 Nm
Maximum current, Imax 42 A
Maximum speed, nmax 2200 /min
Voltage constant, Ke 135V/(1000/min)
DC bus voltage, UDCbusz 540 V
Moment of inertia (without brake), J 224 Kgcm2
Mass, m 56 Kg
Mass with brake, m 59 Kg
Line resistance, R 0.483 Ω
Protection class IP55
Insulation class F
Incremental encoder/resolution ERN1326/4096
Absolute encoder Single/Multiturn ECN1325/EQN1337
Brake Available
